Introduction
This model processing raw material widely, convenient and flexible for (deployment) can beprocessed wood such as all kinds of timber, slab, slat, log core, building templates, etc., and allkinds of non-wood raw materials such as bulk straw wood, cotton, reed, wide application scope.This machine adopts chain plate intelligent feeding, which can automatically adjust feeding speedaccording to the main motor load. It is the ideal equipment for biomass power plant to make themachine run full load to avoid idle running, make the feed flow more smoothly and greatly improvethe production capacity.
Specification
|
Model |
HL1800-800 |
HL2000-1000 |
|
Rotor diameter (mm) |
800 |
1000 |
|
Cutter quantity (piece) |
4 or 25 |
4 or 24 |
|
Input size (mm) |
1800-800 |
2000-1000 |
|
Rotor rotation speed (rpm) |
900 |
900 |
|
Max material diameter (mm) |
500 |
600 |
|
Production capacity (TPH) |
40-45 |
45-50 |
|
Main motor power (kw) |
315 |
400 |
|
Feed motor power (kw) |
11 + 7.5 |
11 + 7.5 |
|
Discharge motor power (kw) |
5.5 + 11 |
4 + 5.5 |
|
Oil pump motor power (kw) |
4 |
3 |
|
Chain feed conveyor length (m) |
6 |
5 |
|
Discharge conveyor length(m) |
10 |
10 |
|
Weight (t) |
28 |
32 |
|
Dimension (m) |
12.5 x3.2 x3.5 |
13 x3.5 x3.7 |
